  • Single Channel
  • Astronomical and annual programs
  • 10 year power reserve (lithium battery)
  • 40 programa
  • Automatic summer/winter time switchover
  • Holiday mode
  • Random mode
  • Multi-language
  • Automatic transfer of weekdays
  • 24-264V AC/DC input supply
  • Sealable cover of the front panel easy  setting by 4 keys
Technical data
Supply terminals A1~A2
Rated voltage AC220-240V
Rated frequency 50/60Hz
Power consumption 1W
Supply voltage tolerance ±10%
Number of channels Single channel
Number of programs 40
Program weekly, annual and astronomical
Mode of work manual, automtic, holiday, random
Summer/ winter time off, automtic changeover
Time tolerance ≤1s/day at 20℃
Power reserve 10 years
Data readout LCD display with backlit
Number of contacts 1C/O
Current of contacts 16A/250V AC1
Switching capacity 4000VA/AC1, 384W/DC
Mechanical life 106
Electrical life 105
Rated insulation voltage 250V
Standard IEC60947-1/IEC60947-2-7
Dimensions 90*36*64mm

Wiring and Dimension [mm:]
